韩国FOOTMASTER福马脚轮 |
|
|
|
|
|
 |
 |
设计说明 |
| 每个允许承载Load capacity/pce |
|
| 四个允许承载 (Recommended load/4 pcs) |
|
| 净重(Net weight) |
|
0.9kg (2.0Ibs) |
|
1.1kg (2.5Ibs) |
| 使用温度(Temperature range) |
|
|
|
使用材料说明 |
①底板(Top plate) |
F-type : Pressed steel / S-type : Forged steel |
②支架(Frame) |
Aluminum diecasted |
③支撑垫(Leveling pad) |
Ball bearing #608zz |
④调节轮(Handle) |
橡胶(聚氨脂/NBR(Polyurethane, Anti-static polyurethane available by order) |
⑤ 轮子(Spring) |
尼龙-6(Nylon-6) |
⑥固定螺栓(Mounting bolt) |
S-type(丝杆型) |
M12x1.75P |
F-type (底板型) |
4-M6x1.0P |
⑦ 表面处理 (Surface treatment) |
粉喷及镀锌(Powder coated & Zinc galvanized ) |
|
|
|
|
